UL 498 Standard Plug Socket Tester Push Out Tool With Calibration Certificate
Thông tin chi tiết sản phẩm:
| Place of Origin: | China |
| Hàng hiệu: | Kingpo |
| Chứng nhận: | Calibration Certificate |
Thanh toán:
| Minimum Order Quantity: | 1 |
|---|---|
| Giá bán: | To be quoted |
| chi tiết đóng gói: | gói thùng carton an toàn hoặc hộp ván ép |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 Pieces/month |
|
Thông tin chi tiết |
|||
| Place of origin: | Guangdong,China(mainland) | Standard: | UL 498 |
|---|---|---|---|
| Điểm nổi bật: | electrical socket tester,hardness testing equipment |
||
Mô tả sản phẩm
UL498 Figure 118.3 | Push Out Tool
| American Standard UL498 plug and socket gauge | ||||
| Gauge | drawing number | standard number | number name | |
| 1 | Articulate probe with web stop | Figure 9.1 | UL 498 | 1 |
| 2 | Probe | figure 10.1 | UL 498 | 1 |
| 3 | Flat probe | figure 31.1 | UL 498 | 1 |
| 4 | Reference plug | |||
| 5 | the simulation of plug tension device should a figure | figure 69.1 | UL 498 | 1 sets |
| 6 | Improper insertion test blades | figure 94.1 | UL 498 | 2 |
| 7 | Test plug | figure 105.1 | UL 498 | 2 |
| 8 | Test blade | figure 105.2 | UL 498 | 1 |
| 9 | Receptacle test fixture | figure 118.1 | UL 498 | 1 |
| 10 | Push out tool | figure 118.3 | UL 498 | 1 |
| 11 | Bridge | figure 118.5 | UL 498 | 1 |
| 12 | Test pin A | figure 119.1 | UL 498 | 1 |
| 13 | Test pin B | figure 119.2 | UL 498 | 1 |
| 14 | 57g ground pin | figure 119.3 | UL 498 | 1 |
| 15 | 113g ground pin | figure 119.4 | UL 498 | 1 |
| 16 | No.14AWG test pin | figure 129.2 | UL 498 | 1 |
| 17 | Test probe | figure 132.1 | UL 498 | 1 |
| 18 | Fixture for assembly security test | figure 144.2 | UL 498 | 1 |
| 19 | Over size ground pin | figure SD 13.2 | UL 498 | 1 |
